Walkaround Models • Owner’s Manual Supplement Chapter 12: Electrical System
Alternating Current (AC) System (2502 Only)
• The 120V/60Hz AC system can be
energized by shore power.
• The master circuit breakers, located
on the AC panel, provide power
source selections to AC powered
accessories. Individual breakers must
be turned On to supply power to the
accessories you wish to use.
• The AC panel may contain inactive
circuit breakers for accessories that
are not available for this model boat.
WATER HEATER DAMAGE HAZARD!
• DO NOT turn on the water heater AC panel electrical circuit until the water heater tank is
COMPLETELY filled with water.
• The tank is full if water flows from the tap when the hot water is turned On in the galley.
• Even momentary operation in a dry tank will damage the heating elements.
• Warranty replacements WILL NOT be made on elements damaged in this manner.
CAUTION
!
When using the shore power, the simultaneous use of several AC components can result in an
overloaded circuit. It may be necessary to turn Off one or more accessories in order to use
another accessory.
NOTICE
AC PANEL
