Chapter 7: Plumbing
Bilge Pump(s)
Bilge Pump System Views
1802
Discharge of oil, oil waste or fuel into navigable waters is prohibited by law. Violators are sub-
ject to legal action by the local authorities.
NOTICE
FORWARD BILGE DRAIN
THRU-HULL
AFT BILGE DRAIN
THRU-HULL
AFT BILGE PUMP &
FLOAT SWITCH
FORWARD BILGE PUMP &
FLOAT SWITCH
