Chapter 7: Plumbing Walkaround Models • Owner’s Manual Supplement
2352 Baitwell System
Hull & Deck Views
SEAWATER PICKUP
& SEACOCK
PICKUP PUMP
HULL ROUTING
NOTE: VIEW IS UNDERSIDE OF DECK
STARBOARD
DECK ROUTING
FROM PICKUP
PUMP
DRAIN
THRU-HULL
Y-VALVE
(IF EQUIPPED)
AERATOR VENT
BAITWELL TANK
SEAWATER
WASHDOWN
DECK FITTING
(IF EQUIPPED)
TO Y-VALVE
(PRO PACK)
TO BAITWELL
(STANDARD)
