Chapter 3: Locations Walkaround Models • Owner’s Manual Supplement
2502
TACHOMETER, TRIM &
TEMPERATURE GAUGE
TACHOMETER, TRIM &
TEMPERATURE GAUGE
COMPASS
SPEEDOMETER, VOLTMETER
& FUEL GAUGE
SHIFTER/THROTTLE
LEVERS
IGNITION PANEL
IGNITION PANEL
(IF EQUIPPED)
SYSTEM MONITOR
(IF EQUIPPED)
SYSTEM MONITOR
(IF EQUIPPED)
TRIM TAB SWITCHES
DC BREAKER
PANEL
SWITCH
PANEL
