30
Chapter 3: Locations Walkaround Models • Owner’s Manual Supplement
Waste Holding Tank (If Equipped):
• 2302/2352: Access is through the
storage compartment below the
starboard seat.
• 2502: Access is through the utility
room access hatch in the cabin.
Waste Pump-Out Deck Fitting
(If Equipped):
• 2302/2352: Located on the port
side of the deck just above the
port deck trail steps.
• 2502: Located on the starboard
side of the deck, above and out-
board of the starboard deck
trail steps.
Water Fill Deck Fitting
(If Equipped):
• 2302/2352: Located at the aft end
of the port deck trail.
• 2502: Located on the port side of
the deck, above and outboard of
the port deck trail steps.
STORAGE
COMPARTMENT
2302/2352
UTILITY ROOM ACCESS HATCH
2502
WASTE PUMP-OUT
DECK FITTING
(IF EQUIPPED)
WATER FILL
DECK FITTING
(IF EQUIPPED)
WASTE PUMP-OUT
DECK FITTING
(IF EQUIPPED)
WATER FILL
DECK FITTING
(IF EQUIPPED)
2302/2352
2502
