Operation
Image Button Description
Laser head control button X/Y
•
Press one of these buttons to manually move the laser
head to the right, le, front or back (travel distance in X/Y-
direction).
•
Press two of the for Laser head control buttons X/Y
simultaneously in diagonal direction to move the laser in
diagonal direction (X+/Y+, X+/Y-, X-/Y-, X-/Y+).
•
Press the Shi-button together with one any desired Laser
head control button X/Y to move the laser head quickly to
the corresponding end position.
Working table control button Z Table moves up or down.
Stop-button
•
Press this button to stop the current working process.
Start/Pause/Repeat-button Start:
•
Press this button to start a job. The job has to be on the
plate in JobControl®.
Pause:
•
Press this button to pause the job (LED On) which is
currently being processed. Press this button again to
continue the job (LED Off).
Repeat:
•
Press this button aer a job was finished to repeat the actual
job.
50
