Maintenance
8.3.2 Optics in general
Trotec Laser GmbH recommends to use the cleaning set enclosed. Alternatively, use high-quality cotton swabs together
with the provided cleaning liquid.
Notice
The following cleaning products are available as accessory parts:
– Lens cleaning cloth
– Lens cleaning liquid
8.3.3 Lens
1. Remove the air assist
hose.
2. Now remove the lens and
check the surface. Here:
2.0 inch lensRemove
loose particles and
dust with a bellows or
compressed air (ISO
8573:2010 Class 1).
3. Remove the lens and
rinse it with cleaning
fluid. Apply some lens
cleaning fluid to the lens
and let it soak in for 1
minute.
4. Clean the lens carefully
and without pressure
with the lens cleaning
cloth.
5. Put the tube back on the
laser head.
6. Insert lens.
64
