Maintenance
System Components Daily Weekly Quarterly Half-yearly Yearly
Vent slots of exhaust box.
(inside the machine)
✓✓
Entire working area.
General cleaning.
✓
Vent slots (backside of the
maschine)
✓✓
Spindles Clean and
grease.
Cover of the laser source and
housing.
✓
Axis rails in x and y-direction Clean and
lubricate
✓ ✓ Check and clean whenever required.
✓ Clean whenever required.
Notice
In order to ensure the maximum availability and lifetime of the system, we recommend that you regularly
check the filter, ventilation and exhaust slots and keep the surrounding area clean. A visual inspection of
the lenses is likewise recommended before switching on the system.
8.3 Cleaning
8.3.1 Machine
1. Move the working table into a position in which it is easiest for you to clean the surface with a window cleaning
agent and paper towels.
2. Switch off and disconnect the machine from the mains.
3. Open the transparent acrylic top lid and front panel.
4. Thoroughly remove all loose dirt particles and deposits in the interior of the machine (e.g. with a vacuum cleaner or
broom).
5. Clean the air guide plate and vent slots of the exhaust box inside the machine using a dry or damp cloth or brush.
6. Clean the cover of the laser source and vent slots at the back of the machine using a dry or damp cloth.
7. Clean the transparent acrylic top lid using a dry or slightly damp cotton cloth. Do not use paper towels as they could
scratch the acrylic.
63
