8060 Q400 DC/RF – Technical Specifications
Mechanics
Working area
1030 mm x 630 mm (40.55 x 24.8 inches)
Loading area 1130 mm x 690 mm (44.45 x 27.17 inches)
Working piece table
Aluminium cutting grid table or aluminium slat cutting table
Software controlled Z-axis with servo motor
Max. Z-height
200 mm (7.87 inches)
Max. engraving speed
2 m/sec. (78.74 in/sec.)
Acceleration 15m/s² (590 in/sec²)
Max. cutting speed
0.7 m/sec. (27.56 in/sec.)
Motor
Servo motors
Optical elements
Mirrors, lens air-flushed for soil-protection
Lenses
2.0", 4.0“
Max. material load Max. 20 kg
Laser class
Class 2 – Safe operation thanks to the closed housing secured with interlocks
Features standard and accessories
Software
JobControl® Expert printer driver, JobControl® Expert laser software
Compatible with standard graphic and CAD software like Corel Draw, Adobe Illus-
trator, …
Ruby® ab Version 2.5
InPack Technology™
Protection of moving parts against dust
Air-Assist
Coaxial air assist incl. integrated pump
Laser pointer 655nm, <0,99mWcw
Laser source
Adjusted and reviewed laser source integrated
Water-cooling
DC-Version includes the chiller within the scope of delivery
16 l/min
Connection for exhaust
Adjustable cabinet exhaust, adjustable table exhaust
Ports: 1 x 90 mm (3.5 in) outer diameter
Additional standard features
Kill and key switch, LED-lighting, electrical Z-axis, OptiMotion™, air-cooled optics,
2.0” lens, air-assist nozzle (Ø3mm und Ø7 mm), focus-tool, aluminium cutting grid
table, laser class 2, CE certification, RJ45-connection for external variable power
meter
