Operation
Assembly with a 2.0 inch lens Assembly with a 4.0 inch lens
Notice
Make sure that the lens is placed with the convex side facing upwards.
7.7 Table placement
1. Press the silver hidden handle to li the table.
2. Remove the table including frame from the machine.
3. Insert the new table including frame into the machine.
Information
The slats and the frame are transported individually. The slats can be positioned individually in the frame
as required.
53
