Maintenance
POSITION 3 OF 3: LUBRICATE Y-AXIS AT REAR POSITION
•
Remove the le side cover.
•
Move the x-axis to the far le (back of the working
table).
•
Lubrication nipple should be accessible and concentric
with hole.
•
Press two pump strokes of the grease gun into the
lubrication nipple.
•
If required: Remove excess grease with paper towel.
•
Replace the side cover.
71
