Tru-Test WOW2 Service Manual

EziWeigh5i, EziWeigh6i, EziWeigh7i, WOW2, DAS WOW2
Issue 2, 7/2017 10
Parts list
Description
Contents
Quantity
per indicator
Part number
LCD 7 segment All models 1 828687P
LCD dot matrix EziWeigh6i, EziWeigh7i, WOW2 and DAS
WOW2
1 815787P
Load bar connector and
FPC
Male connector. All models
2
830037P
Power/communication
connector and FPC
Female. All models 1 830036P
Battery All models 1 828688P
PCA (printed circuit
assembly)
EziWeigh5i
EziWeigh6i
EziWeigh7i
WOW2
DAS WOW2
1
1
1
1
1
828684P
828685P
828686P
829037P
830504P
Case front (clear) All models 1 816748P
Case bezel (yellow)
All models
1
816747P
Case rear (yellow)
All models.
1
828690P
O-ring All models 1 816749P
Sound hole label kit
EziWeigh5i
Kit of 10 x 20 mm round labels used to cover the
sound hole in the case front.
1
828692P
Foam block kit EziWeigh5i
5 x foam blocks 80x30x14 for packing between
the case front and the PCA.
1 829778P
Piezo speaker
EziWeigh6i, EziWeigh7i, WOW2 and DAS
WOW2
Includes the round, double-sided label used to
affix the speaker to the case front.
1
830459P
Screw kit case All models
Kit of 50 screws used for securing the case
components
11 816752P
Screw kit C16 All models
Kit of 50 screws used for securing
power/communication and load bar connectors
6 SSS20416P
Screw kit LCD/PCA All models
Kit of 50 screws used for securing the LCD and
PCA.
8 (EziWeigh5i)
or
10 (EziWeigh6i,
EziWeigh7i,
WOW2 and DAS
WOW2)
816753P
Overlay
EziWeigh5i
EziWeigh6i
EziWeigh7i
WOW2 and DAS WOW2
1
1
1
1
829034P
829035P
829036P
829038P
Keypad All models 1 816597P
