Tru-Test WOW2 Service Manual

EziWeigh5i, EziWeigh6i, EziWeigh7i, WOW2, DAS WOW2
Issue 2, 7/2017 34
Accessing the hidden menus
These menus provide access to indicator settings. They are for Tru-Test staff and authorised service
personnel only.
Warning! Changing settings in these screens may change the operation of the indicator.
EziWeigh5i ESC+MENU hidden menu
Hold and press to access the ESC menu (use EziWeigh6i or EziWeigh7i overlay on top of
EziWeigh5i overlay).
Press
to exit from menu once changes have been made.
Span calibration
Press until displays SPAn.c . See the technical bulletin Span Calibration Guide to
perform span and sensitivity calibrations.
Damping options
Press until displays d.SYSt .
Press .
Press or to select CAtLE (cattle), SHEEP (sheep), F.t. (best
weight in fixed weigh time) or AuG (averaging) options.
Damping time options
Press until displays LEnGt .
Press .
Press or to select 0.1 S to 6 S (averaging and fixed time options
adjustable from 0.1 to 6 seconds).
Diagnostics
Press until displays diAG. .
Press .
Press
or to select. Press .
codE (load cell code – identifies the type of load bars or load cell connected to the indicator
so that the correct capacity, resolution and sensitivity can be selected. It is determined from two
resistors installed in each load cell connector.),
