PEX-1000 Series
Print Engine Service Manual
35
4.2 Mechanism Fine Adjustment to Avoid Ribbon Wrinkles
This printer has been fully tested before delivery. There should be no ribbon wrinkle
presented on the media for general-purpose printing application. Ribbon wrinkle is related to
the media width, thickness, print head pressure balance, ribbon film characteristics, print
darkness setting…etc. In case the ribbon wrinkle happens, please follow the instructions
below to adjust the printer parts.
Pressure
position
The pressure position can be adjusted by using a coin. Please use a coin
to release the fixing screws as below show.
When using label its width is smaller than 2 inch. Please release the right
side of pressure knob. Only use left side pressure
left side position, too. Once you find a position that has balance pressure
on the label, the wrinkle will disappear.
screws
To Next Page
