14
14
PEX-1000 Series
Print
Engine Service Manual
3.4 Replacing the Power Supply Unit
1. Refer to section 3.3 to remove the electronics cover.
2. Disconnect three connectors as shown.
3. Remove two screws on power supply cover.
