37
Note: If printing from enclosed software/driver, the software/driver will send out the commands, which will overwrite the settings set
from the panel.
Item
Description
Default
Speed
Set the print speed.
N/A
Density
Set the printing darkness.
8
Direction
Set the printout direction. Setting Value: 0 and 1.
Direction 0: Direction 1:
0
Print mode
Set the print mode. There are 5 modes in total:
None: Next label top of form is aligned to the print head burn line location. (Tear Off Mode)
Batch Mode: Once finishing the printing process, label will be fed to the tear plate location.
Peeler Mode: Enable the label peel off mode.
Cutter Mode: Enable the label cutter mode.
Cutter Batch: Cut the label once at the end of the printing job.
Batch Mode
Offset
Adjust media stop location. Available value setting range: -999 dots to 999 dots.
0 dot
Shift X
Adjust print position. Available value setting range: -999 dots to 999 dots.
0 dot
Shift Y
0 dot
Reference X
Set the origin of printer coordinate system horizontally and vertically. Available setting range: 0 dot to 999
dots.
0 dot
Reference Y
0 dot
Code page
Set the code page of international character set.
850
Country
Set the country code. Available setting value range: 1 to 358.
001
