TSC TDP-245 Plus Service Manual

7
Bar code
1D bar code
Code 39, Code 93, Code128UCC, Code128 subsets
A.B.C, Codabar, Interleave 2 of 5, EAN-8, EAN-13,
EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits
add-on, MSI, PLESSEY, POSTNET, RSS-Stacked,
RSS14, Code 11, China Post
2D bar code
PDF-417, Maxicode, DataMatrix, QR code, Aztec
Font & barcode rotation
0, 90, 180,270 degrees
Command set
TSPL-EZ
TM
Media type
Continuous, die-cut, black mark, fan-fold, notch
Media wound type
Outside wound
Media width
20~112mm (0.78" ~ 4.4")
Media thickness
0.06~0.19 mm (2.3~7.4 mil), max. 150g/m
2
Media core diameter
25.4~76.2 mm (1”~3”)
Label length
Min. 10 mm (0.4”)
Label length (peeler mode)
25.4~152.4 mm (1”~6”)
Label length (cutter mode)
25.4~2286 mm (1”~90”)
25.4~1016mm (1”~40”)
Gap height
Min. 2 mm
Black mark height
Min. 2 mm
Black mark width
Min. 8 mm (0.31”)
Printout bias
Vertical: 1 mm max.
Horizontal: 1 mm max.
Environment condition
Operation: 5~40
o
C (41~140
o
F), 25~85% non-condensing
Storage: -40~60
o
C (-40~140
o
F), 10~90% non-condensing
Safety regulation
FCC Class B, CE Class B, C-Tick Class B, UL, CUL,
TÜ V/Safety, CCC
