37
3.12.
Cutter Module I
nst
allati
on (Option)
2.
Pull the
top cover open levers to open the top cover
.
3.
Remove the front panel from the low
er cover
.
4.
Use a screwdriver to screw of
f
6 screws on the
lower inner cover
.
Remove 6 screws from lower inner cover
5.
T
u
rn the printer upsi
de down.
6.
Remove the screw that fixes the memory card cover
.
7.
Plug in the Cutter Driver IC at U30 socket on the main board.
Screws
Screws
Screw
Cutter Driver IC
39
41
