TSC TDP-245 Plus Service Manual

2
1.3. Specification
1.3.1. Printer (TDP-245 Plus)
Item
Printer model
TDP-245 Plus
Resolution
203 DPI
Printing method
Direct Thermal
Print speed
2, 3, 4, 5 ips.
2, 3 ips for peel model
Max. print width
108 mm (4.25”)
Max. print length
2286mm (90”)
Enclosure
Double-walled plastic
Physical dimension
240mm (L) x 200mm (W) x 164mm (H)
Label roll capacity
5” OD
Processor
32-bit RISC high performance processor
Memory
 2MB Flash memory
 8MB DRAM
 SD card slot for memory expansion
Interface
 RS-232 (max. 115200 bps)
 Centronics
 USB 2.0 (Full speed mode)
Power
External universal switching power supply
 Input: AC 100-240V
 Output: DC 24V 3.75A
Operation switch, button
One power switch & feed button
Sensors
 Gap transmissive sensor (offset 6 mm from center)
 Black mark reflective sensor (position adjustable)
 Head open
Internal font
 8 alpha-numeric bitmap fonts
 One Monotype Imaging® CG Triumvirate Bold
Condensed scalable font
