24
3.5
. Replacing Label
Guide
A
djustment K
nob
A
s
sembl
y
1.
Please refer to 3.2 for disassembling the low
er cover
.
2.
Shift the label guide to
the
ce
nter
by rotating t
he label guide adjustment knob.
3.
Use a flat screwdriver to press the nub to remove the label guide adjustment
knob.
3. Remove 4 screws.
Screws
Screws
Plastic Lami
nate
Label Guide
Label Guide
Adjustment Knob
Lower Inner Cover
Nub
26
28
