3.11.1 Loading Label for Peel-off Mode (Option)
Open the peel-off panel
1. Feed the label, printing side facing up, through the label guide and pass over the
platen.
2. Lead the liner paper through the label opening of peel off module, which is beneath
the roller.
3. Adjust the center-biased label guides in or out by turning adjustment knob so they
are slightly touch the edges of the label backing.
Loading label for peel-off mode
4. Push the peeler back to the printer.
5. Close the top cover.
