1. OVERVIEW
1.1 Front View
1.2 Rear View
Top Cover Open Lever
Feed Button
Clear Window
1. USB Interface
2. Centronics Interface
3. RS-232 Interface
4. Power Jack
5. Power Switch
6. Rear Paper Guide
1 2 3 4 5
6
