TSC TDP-245 Plus Service Manual

12
1.4. Supply Specification
1.4.1. Paper
Item
Specification
Type
Label (Continuous , Die-cut , Fan-fold)
Wound Type
Outside wound
Width
20mm ~ 112mm (0.79” ~ 4.4”)
Length
(Peel-off and cutter mode)
10mm ~ 1000mm (0.4” ~ 39”)
25.4mm ~ 1000mm (1” ~ 39”)
Thickness
0.06mm ~ 0.19mm (max. 150g/m**2)
Roll Diameter
Max. 5”
Roll Core Diameter
25.4mm ~ 76.2mm (1” ~ 3”)
Gap Height
Min. 2 mm (min.)
Black Mark Height
Min. 2 mm (min.)
Black Mark Width
Min 8 mm (min.)

TSC TDP-245 Plus Specifications

General

Brand	TSC
Model	TDP-245 Plus
Category	Barcode Reader
Language	English
