TSC TDP-245 Plus Service Manual

11
Force Gap Sensor
Calibration
1. Turn off the power switch.
2. Hold on the button then turn on the power switch.
3. Release the button when LED turns red/amber after 5
green/amber blinks. (Any red/amber will do during the 5
blinks).
 The LED color will be changed as following:
Amber  red (5 blinks)  amber (5 blinks)  green (5
blinks)  green/amber (5 blinks)  red/amber (5
blinks)  solid green
Skip AUTO.BAS
1. Turn off printer power.
2. Press the FEED button and then turn on power.
3. Release the FEED button when LED becomes solid green.
 The LED color will be changed as following:
Amber  red (5 blinks)  amber (5 blinks)  green (5
blinks)  green/amber (5 blinks)  red/amber (5
blinks)  solid green
4. Printer will be interrupted to run the AUTO.BAS program.
