5. Use a screwdriver to screw off 1 screw on the bottom.
6. Hold the lower cover and lift up the top cover open levers to separate the lower
inner cover and the lower cover.
1. Plug the connector (red) of peel-off assembly at the location JP19 on the main
board. Pull the wire of the red connector through the slot of lower inner cover front
side. Then, put back the lower inner cover.
7. Install the peel-off module to the lower inner cover slot.
8. Gently push peel-off panel to lock to the lower inner cover.
