3.2 Replacing the Main Board
1. Please refer to the section
3.1 to remove the lower
cover.
2. Remove two screws on
the main board.
3. Disconnect all connectors
on the main board.
4. Remove/Replace the main
board assembly.
5. Reassemble the parts in
the reverse procedure.
