3.11 Cutter Module Installation (Option)
1. Open the printer cover to
remover the lower front
panel.
2. Put the cutter module
harness through the slot of
the lower inner cover front
side.
3. Gently place the cutter
module into the both sides of
niches on lower inner cover,
then push cutter to lock into
the lower inner cover.
