TSC TX200 Series - Rear View

TX200/ TX300/ TX600
Bar Code Printer Service Manual
5
1.3 Rear View
Note:
* Recommended MicroSD card specification.
Type
SD card spec
SD card capacity
Approved SD card
manufacturer
Micro SD
V2.0 Class 4
4G
Transcend
V2.0 Class 4
8G
Transcend
V3.0 Class 10 UHS-I
16G
Transcend
1. Power jack socket
2. RS-232C interface
3. Ethernet interface
4. * Micro SD card socket
5. USB interface
6. USB host
7. Centronics interface
8. External label entrance chute
The interface picture here is for reference only. Please refer to the product
specification for the interfaces availability.
