TX200/ TX300/ TX600
Bar Code Printer Service Manual
17
3.3 Replacing the Stepping Motor Module
1. Please refer to the section 3.1
to remove the lower cover.
2. Remove three screws as
shown.
3. Remove four screws as
shown.
4. Remove the hook module
assembly.
