TSC TX200 Series - 2 Electronics; Summary of Board Connectors

TX200/ TX300/ TX600
Bar Code Printer Service Manual
7
2. ELECTRONICS
2.1 Summary of Board Connectors
Main board
Connector
Description
Remark
1
Power supply output (24V DC) connector
B800
2
Power switch cable connector
J800
3
ESD_GND_PIN
J802
Pin
Description
Voltage
1
GND
0V
2
GND
0V
4
RS-232C connector
J201
5
RTC battery (Factory option)
BT800
6
ESD_GND_PIN
J805
1
2
4
5
7
9
10
11
12
13
14
15
16
17
18
19
20
21
22
24
23
25
26
27
28
29
32
35
34
8
30
31
33
3
6
