3.2 Loading the Ribbon
1. Open the printer’s top cover by pulling
the top cover open levers located on
each side of the printer and lifting the
top cover to the maximum open angle.
2. Open the ribbon access cover and the
media cover.
3. Insert the rewind spindle into the
paper core.
