6.3 TSPL2
This “TSPL2” category can set up the printer settings for TSPL2.
Item
Description
Default
Speed
Use this item to setup print speed.
N/A
Density
Use this option to setup printing darkness. The available setting is
from 0 to 15, and the step is 1. You may need to adjust your density
based on selected media.
8
Direction
The direction setting value is either 1 or 0. Use this item to setup the
printout direction.
DIRECTION 0
DIRECTION 1
0
Print mode
This item is used to set the print mode. There are 5 modes as below,
Printer Mode
Description
None
Next label top of form is aligned to the print head burn
line location. (Tear Off Mode)
Batch Mode
Once image is printed completely, label gap/black
mark will be fed to the tear plate location for tear away.
Batch
Mode
Menu TSPL
Speed
Density
Direction
Print mode
None
Batch Mode
Peeler Mode
Cutter Mode
Cutter Batch
Offset
Shift X
Shift Y
Reference X
Reference Y
Code Page
Country
FEED
