- 20 -
3.3.3 Loading Media in Peel-off Mode (Option)
1. Please refer to section 3.3.1 to feed the
paper, printing side face up, through the
paper guide and pass over the platen.
2. Move the media guides to fit the label width
by pushing the media guide adjustment
button.
3. Close the top cover gently. Use “Diagnostic
Tool” to set the media sensor type, calibrate
the selected sensor and set the post-print
action to “PEEL”.
Note:
Please calibrate the sensor before loading media into
the peel-off module for avoiding paper jam.
4. Open the top cover gently. Pull the label
through the front of the printer and take
some labels off only leave the liner.
5. Open the peel-off cover. Feed the liner into
peel-off cover slot.
To Next Page
