Connecting Computer to Flow Meter
7
RS232 Communication Utilizing a USB A to RS232
Adapter
Another method for communicating to the GP Flow instrument is to
utilize a USB to RS232 adapter and then communicate to the
computer using RS232 protocols.
The first step is to connect a USB to RS232 converter to the GP Flow
instrument. The converter must be based on the FTD based drivers
for it to function with the GP Flow instrument. TSI sells a converter
tested to work with the instrument P/N 5000-RS232. After attaching
the converter, the GP Flow instrument must be rebooted. See
graphic below.
I n f o r m a t i o n
The 5000 Series instrument must be rebooted after
attaching the USB to RS232 adapter.
Once the meter has been rebooted, a DB9 Null modem serial cable
can be attached to the computer.
I n f o r m a t i o n
The serial cable between the GP Flow instrument and
the computer must be a null modem cable.
