Operation
Knob
P/N:901169
Rate
Indicator
Temperature
Indicator
SystemPower
(ON/OFF)
BlueLEDindicatesunit
ispoweredon.
Pressure
Indicator
Current
Product
CurrentK‐Factor&
LastCalibrationDate
MountingBracket
P/N:900040
OUTPUT:ConnecttoRS‐232
printer
P/N:900064
CurrentDate&Time
PCO(PumpControl):Connectto
PumpControl
P/N:900062
FlowIndicator
(WHITELED
illuminatedor
flashingindicates
presenceofflow)

GrandTotalizer
(Non‐Resettable)
SystemAlarm
(RedLEDflashing
signalsactive
alarm)
DataPort
(USB)
DeliveryTotal
(Resettable)
PRESS(Pressure):Connectto4‐20mAoutput
P/N:900063
Presstoseeunit
DETAILSlist…alsoused
asascrollupoption
Usedasa“PREVIOUS,”scrolldownnavigation
buttonaswellasa“RESET”option
Printbutton(if
printingisenabled)as
wellas“NEXT”option
Presstoseelistof
“CurrentAlarms”or
“Cancel”
AlarmIcons
becomevisibleas
variousalarmsare
detected
TEMP(Temperature):Connect
totemperatureprobe
P/N:900039
SIGNAL:Connecttoturbine
flowmeter
P/N:900038
POWER:Connecttopower
supply
P/N:900037
