Page 9 of 66 Pages
3.3 Operating Conditions
This device is for indoor use only!
The sterilizer should be loaded only with autoclavable material!
The environment shall not exceed an ambient temperature of 40
ºC and a
relative humidity of 85% respectively.
Caution!
Waste water should be brought into the public net in accordance with
the local rules or requirements i.e ONLY NON-HAZARDOUS
LIQUIDS SHALL BE DISPOSED IN PUBLIC SEWAGE!
3.4 Utilities
Electric Power Supply
Model Power Supply
circuit breaker
2540, 3150
1Ph, 230V/50Hz 20A
3850
1 Ph, 230V/50Hz 25A
3870 with switching box
1 Ph, 220-240V/50Hz 25A
3850/70, 5050/75 3 Ph, 400V/50Hz 20A
5050/75
3 Ph, 230V/50Hz 20A
5050/75 with switching box
1 Ph, 230V/50Hz 40A
Compressed Air (ELC models only)
1/2" 2-5 Bar
Tap water (ELC models only)
1/2", 2-5 Bar
Drain (ELC models only)
Withstanding temp. of 80°C
Attention:
The electrical net must be protected with a current leakage safety relay.
The electrical network must comply with local rules or regulations.
3.5 Load on counter
The counter (or shelve, etc.) on which the autoclave shall be placed must
be able to withstand, at least, the following weight:
Model 2540 3150 3850 3870 5050 5075
Weight 65 kg 95 kg 115 kg 140 kg 285 kg 310 kg
3.6 Construction
The main parts of the autoclave are made of materials as indicated below:
Chamber and door are made of stainless steel
Trays are made of stainless steel.
Water reservoirs of models 2540, 3150, 3850, 3870 are made of hard
plastic material.
Water reservoirs of models 5050, 5075 are made of stainless steel.
Door handle is made of hard plastic material, which is safe to touch
and thermo-insulated.
