Rebound damping force
The rebound damping force adjustment is provided
in the left leg only.
To increase the damping turn the adjuster screw
clockwise and to reduce the damping turn the
adjuster screw towards anti-clockwise, as shown.
(ref. Fig. 39)
During adjustment count the numbers of clicks from
fully closed (clockwise) position.
When Adjusting the damping force setting turn the
adjuster screw in clockwise direction until it stops,
noting that the first click counted as 1 then count the
clicks turning in anti-clockwise direction.
Although the damping adjuster may turn beyond the
stated minimum settings, such turns are ineffective and
advised not to turn further, as it may lead to the damage
of damping mechanism.
Note
Fig. 39
