Dimension (D x W x H)
30.31" x 17.24" x 6.93"
(770 x 438 x 176mm)
Motherboard S7109GM2NR-2T
Gross Weight 45 kg (99.5 lbs)
Net weight 26 kg (57.5 lbs)
Front Panel
Buttons
(1) RST, (1) ID, (1) NMI,
(1) PWR w/ LED
LEDs
(1) HDD, (1) ID, (3) LAN,
(1) IPMI/Warning
I/O Ports (2) USB 3.0 port
External Drive
Bay
Type / Q'ty 2.5" Hot-Swap SSD/HDD/ (14)
HDD backplane support SAS 12Gb/s, SATA 6Gb/s
Supported HDD
Interface
(14) SATA 6Gb/s
System Cooling
Configuration
FAN (6) 12cm fans
Power Supply
Type RPSU
Input Range
AC 100-127V/12.9A,
AC 200-240V/9.5A
Frequency
47 - 63 Hz
Output Watts
Max 2000 Watts for 100-127V
AC input, Max 3,200Watts for
200-240V AC input
Efficiency
PFC, 80 plus Platinum
Redundancy
2+1
NOTE: When use 100V-127V AC
input, the system does not support
redundant PSU operation if the
total system load exceeds 20A
(2000 Watts)
Processor Socket Type / Q'ty LGA3647/ (2), *Socket-F support
