1.4 Standard Parts List
This section describes FT77D-B7109 package contents and accessories. Open the
box carefully and ensure that all components are present and undamaged. The
product should arrive packaged as illustrated below.
1.4.1 Box Contents
FT77D-B7109 Chassis Kit
(1) 4U chassis
(2+1) 3,200W (80+ Platinum) w/ PFC redundant power supply
(6) 120X120X38MM Fan (pre-installed)
(1) S7109 Motherboard (pre-installed)
(1) M1284F77D-BP12E-14 HDD Backplane Board (pre-installed)
(1) M1713F77C-FPB Front Panel Board (pre-installed)
(1) M7059F77C-D-PDB Power Distribution Board (pre-installed)
(1) M7109F77D-D-PBP Power Backplane Board (pre-installed)
(1) M1809F77A-FB Fan Board (pre-installed)
(1) M2215-L8-1F riser card (pre-installed)
(1) M2093 riser card (pre-installed) --- only for B7109F77DV10E4HR-2T-N
1.4.2 Accessories
If any items are missing or appear damaged, contact your retailer or browse to
TYAN’s website for service: http://www.tyan.com
FT77D-B7109 Accessory Kit
(1) Rail kit + (1) Rail screw kit
(1) Card Guide kit
(1) Screw Pack
(2) CPU heatsink
(3) US power cord
(3) EU power cord
(1) Mounting ears
(16) 2*3P GPU power cable
(8) 2*4P GPU power cable
(8) GPU card Holder Bracket (only for GPU card bundle SKU) w/ screw
(8) 2*4P GPU power cable for K80 GPU
(1) Air duct
(2) CPU clip
(2) Fabric CPU clip (only for Fabric CPU bundle SKU)
(1) Tyan Drive CD
(1) Addendum for China Use Only
To Next Page
