3.6.1 Fan Board Features
M1809F77A-FB Fan Board
Specifications
Support (6) 120x38 mm system FAN
(4) 4-pin B4P RA PWR Connector (run DC+12V)
(6) 4-pin Hot-swap FAN Connector
(1) 20-pin barebone system FAN connector to MB
FAN Sequence
