2.2 Rack Mounting
After installing the necessary components, FT77D-B7109 can be
mounted in a rack using the supplied rack mounting kit.
Rack mounting kit
Rail with Bracket x 2
Mounting Ears x 2
Screw Sack x 2
NOTE: The users have to prepare two screws and two nuts on their own
for rack mounting.
2.2.1 Installing the Server in a Rack
Follow these instructions to mount the FT77D-B7109 into an industry
standard 19” rack.
Note:
Before mounting FT77D-B7109 in a rack, ensure that all
internal components have been installed and that the unit
has been fully tested.
