3.10.1 Power Backplane Board Features
Front View
Rear View
M7109F77D-D-PBP Power Backplane Board
Specifications
(3) Power supply Connector for DPS-1600CB A
(1) 24S+6P RA Connector to MB
(1) 24S+6P Connector to M7059F77C-D-PDB
(1) ATX 8-pin PWR Connector
