26
Feature
Hardware Monitor, SMBIOS
3.0/PnP/Wake on LAN, Boot from
USB device/PXE via LAN/Storage,
User Configurable FAN PWM Duty
Cycle, Console Redirection, ACPI
sleeping states S4,S5, ACPI 6.1
Operating
System
OS supported list
Please refer to our AVL support
lists.
Regulation
FCC (DoC) Class A
CE (DoC) Yes
Operating
Environment
Operating Temp. 10° C ~ 35° C (50° F~ 95° F)
Non-operating Temp. - 40° C ~ 70° C (-40° F ~ 158° F)
In/Non-operating
Humidity
90%, non-condensing at 35° C
RoHS RoHS 6/6 Compliant Yes
Package
Contains
Manual
(1) Web User's manual,
(1) Quick Installation Guide
Installation CD (1) TYAN installation CD
Barebone
(1) FT77D-B7109 w/NV
Tesla-aware FW Barebone
TYAN FT77D-B7109 (B7109F77DV14HR-2T-N)
System
Form Factor 4U Rackmount
Chassis Model FT77D
Dimension (D x W x H)
30.31" x 17.24" x 6.93"
(770 x 438 x 176mm)
Motherboard S7109GM2NR-2T
Gross Weight 45 kg (99.5 lbs)
Net weight 26 kg (57.5 lbs)
