28
Chipset
PCH Intel C621
Switch IC (4) PLX PEX8747
Memory
Supported DIMM Qty (12)+(12) DIMM slots
DIMM Type / Speed
DDR4 RDIMM/RDIMM 3DS/
LRDIMM/LRDIMM 3DS 2666
Capacity
Up to 768GB RDIMM/ 1,536GB
LRDIMM/ 3,072GB RDIMM 3DS/
LRDIMM 3DS *Follow latest Intel
DDR4 Memory POR
Memory channel 6 Channels per CPU
Memory voltage 1.2V
Expansion Slots
PCI-E
(9) PCI-E Gen3 x16 slots,
(2) PCI-E Gen3 x8 slots (one for
Tyan OCP riser card only)
Pre-install TYAN Riser
Card
M2215-L8-1F
LAN
Port Q'ty (2) 10GbE ports, (1) PHY
Controller Intel X550-AT2
PHY Realtek RTL8211E
Storage
SATA
Connector (2) Mini-SAS HD (8-ports)
Controller Intel C621
Speed 6.0 Gb/s
RAID RAID 0/1/10/5 (Intel RSTe)
sSATA
Connector
(2) SATA-III,
(1) Mini-SAS HD (4-ports)
Speed 6.0 Gb/s
RAID RAID 0/1/10/5 (Intel RSTe)
Graphic
Connector type D-Sub 15-pin
Resolution Up to 1920x1200
Chipset Aspeed AST2500
