M1713F77C-FPB Front Panel LED Control Board
Switch and LED Indication
Item Status
LED
Color
Behavior Note
5. LAN1
Access Green Blinking
Link Green Solid On
Off Link Green Off
6. LAN2
Access Green Blinking
Link Green Solid On
Off Link Green Off
7. LAN3 NA NA NA No Function
8. Power
Power On Green Solid On
Power Off Green Off
9. ID
Located Blue Solid On
Free Blue Off
10. HDD Activity Access Green Blinking
11. IPMI / Warning
Normal Amber Off
BMC & HWM system
alert event
(＊) N+1 Redundant
PSU Indication
Alert Amber Solid On
＊Warning LED Indication for 2+1 PSU Redundancy System
Status System Warning LED
All PSU present and plug AC cord when
system power on
Off
One of PSU AC lose Amber solid on
One of PSU not present Amber solid on
