B7109F77DV10E4HR-2T-N
No. Description
1 PSU2
2 PSU1
3 PSU0
4 Mezzanine Card Slot
5 ID LED Button
6 LAN3 (IPMI)
7 LAN2
8 LAN1
9 PCIE Slots
10 PCIE Slot (M2093 pre-installed for NVMe SKU)
NOTE:
1. With every two out of three PSUs can boot up the FT77D-B7109.
2. The FT77D-B7109 can support the redundant power under the
condition when the voltage is 100~127V and the output power is
less than 2000W, or the voltage is 200~240V and the output power
is less than 3200W.
