DESCRIPTION
■ General construction
The transmission case, Engine an
Front Axle Support are
olte
togethe
to for
arigi
unit.
■ Front Axle & Wheels
The 4WD front axle is a center-pivot, reverse Eliot type. The front wheel drive mechanism is
incor
orated as a
art of the axle.
The front wheel drive power is taken off the rear transmission and transmitted to the differential in
the front axle where the power is divided into right and left and to the respective final cases.
In the final cases, the transmitted revolution is reduced by the level gears to drive the front wheel.
The 4WD mechanism with level gears provides wider steering and greater durability.
■ Engine
The tractors are fitted with vertical, Water-cooled 4-cycle and swirl chamber type Mitsubishi
ENGINES.
■ Transmission with HST(Hydrostatic Transmission)
The tractor is fitted HST with two range and can be selected speed range by HIGH- LOW selector
lever. The tractor has two pedals for forward/reverse control. Tractor with Independent Power Take
Off is fitted with electro-hydraulic Clutch Assy. The Rear PTO and Mid PTO can be operated both
or separately by a lever.
■ Brakes
TYM tractors are provided with independent disc brakes operated by two road travel. A foot brake
lever is fitted for parking
■ Rear axle & Wheels
This is mounted on ball bearings and is enclosed in removable housing which are bolted to the
transmission case. The rim & Disc fitted with Rear tires are bolted to the outer flange of Rear Axle.
24
■ H
draulic s
stem & Linka
es.
TYM Tractors are fitted with Live (i.e. system is in operation.) independent, very touch of hydraulic
System. Three point Linkages can be used for category 1 type of implements.
