TYM T293HST - Servicing Transmission; Transmission Oil

SERVICING TRANSMISSION
TRANSMISSION OIL
Th t i i il i d t l b i t d d h d li fl id It i i t t t th
Th
e
t
ransm
i
ss
i
on o
il
i
s use
d
t
o
l
u
b
r
i
ca
t
e an
d
use
d
as
h
y
d
rau
li
c
fl
u
id
.
It
i
s
i
mpor
t
an
t
t
o use
th
e proper
oil. Using the recommendation oil is preferred for better performance. Consult authorized
dealer/distributor for details.
Transmission Oil Capacity : 17ℓ(4.5 US gals)
■
Checking Transmission Oil
■
Checking
Transmission
Oil
1. Park tractor on level surface
2. Lower the implements to ground
3. Shutoff engine. Allow transmission oil to cool
enough.
4. Check the level with the sight window on rear
side of the transmission in rear of the seat. If
the level is low add oil through the filler hole.
CAUTION
Always ensure that you use the correct oil for topping up or oil changes.
IMPORTANT
Always use the same grade and specified oil as replacements.
Dispose off the old oil as per local regulations .
