AIR CLEANER
■ Squeezing Dust
To remove the dust from the evacuator valve squeeze it
between thumb and fingers to let excess dust out and
wipe around the valve to keep it clean from outside.
ean
n
e
emen
1. Open the hood
2. Remove the element by unlocking the clamp.
3. Remove dust by blowing it out of the
element with compressed air.
4. Check the element to ensure it is not damaged.
5. Reassemble the element.
▶ Replace the element after cleaning it 5 times or it is damaged.
IMPORTANT
Never beat the element on a stone or concrete floor/wall to clean it Check all
connections and hoses especially on the clean side of the air cleaner to ensure
no dusty air can enter the engine.
Check the element for flaws by putting a light inside the element.
When reassembling make sure all surfaces seal correctly to keep dust out.
When working in dusty conditions increase the service frequency
When working in dusty conditions increase the service frequency
65
