TYM T293HST - Independent Pto

INDEPENDENT PTO
PTO monitor Lam
p
■ The PTO monitor lamp
On the dash panel indicates the state of the PTO shaft.
1. If the monitor glows: The PTO is On.
2. If the monitor is off: The PTO is off
p
■ PTO ON/OFF Switch
PTO ON/OFF switch is situated on the right hand side on the
instrument panel and can be identified easily with its built in
ldidi Wh h ihi hdd
green co
l
ore
d
i
n
di
cator.
Wh
en t
h
e sw
i
tc
h
i
s pus
h
e
d
d
own to start
the PTO indicator glows to indicate that the switch and the PTO
are in ON position, If the switch is pushed down again the
indicator goes off signaling that the PTO is OFF.
PTO ON,Off switch
The PTO shaft will not rotate if switch is in OFF position.
36
